Tekniset tiedot

Weight

1.4 kg

Size

267,4 x 68,6 x 177,7 mm

Output

1 AUDIO OUT L/R (1/4 inch TS Jacks) 1 PHONES (1/4 inch stereo phone Jack)

USB ports

1 USB B port

Included Accessories

AC adaptor Power cord Quick Start Guide warranty

Sound Generation

Analog synthesis

Programs

99 programmes x 10 banks (5 factory banks, 5 user banks) * Each program includes its own sequence pattern * Able to set up to 13 favourite programmes can be registered

Oscillator 1

Frequency Pulse Width Sync (Off, On)

Oscillator 1 Waveshapes (continuously variable)

Triangle Sawtooth Variable-width Pulse

Oscillator 2

Frequency Fine Pulse Width Key Follow (Off, On) Low Frequency (Off, On)

Oscillator 2 Waveshapes (continuously variable)

Triangle Sawtooth Variable-width Pulse

Oscillators

Slop

Mixer

Oscillator 1 Level Oscillator 2 Level Sub Level Noise Level

Low-pass Filter

Cutoff Resonance Key Amount (Off, Half, Full) Velocity (Off, On)

High-pass Filter

Cutoff Resonance Key Amount (Off, Half, Full) Velocity (Off, On)

Filter Envelope

Low-pass Filter Amount High-pass Filter Amount Attack Decay Sustain Release

AMP Envelope

Amount Velocity (Off, On) Attack Decay Sustain Release

Glide

Rate Off, On Mode (Fixed Rate, Fixed Time, Fixed Rate A, Fixed Time A)

LFO

Frequency Sync (Off, On) Initial Amount

LFO Shapes

Triangle Reverse Sawtooth Sawtooth Square Random

LFO Destination

Oscillator 1 Frequency Oscillator 2 Frequency Oscillator 1 and 2 Pulse Width Low-pass Filter Cutoff High-pass Filter Cutoff VCA

Modulation Source

Filter Envelope Oscillator 2 Amount

Modulation Destination

Oscillator 1 Frequency Oscillator 1 Shape Oscillator 1 Pulse Width Low-pass Filter Cutoff High-pass Filter Cutoff

FX 1 Types

Bucket-brigade Delay Distortion Ring Modulation

FX 2 Types

Chorus Low Resonance Phaser High Resonance Phaser Maestro Phaser

Parameters

Each effect has 2 adjustable parameters

Keyboard

13-key touch keyboard 22 preset scales 9 octaves: C0 ~ C9 (use with Oscillator 1 and 2 frequency parameters)

Slider Parameters (multi assignable)

Oscillator 1 Frequency Oscillator 2 Frequency Low-pass Filter Amount High-pass Filter Amount LFO Amount FX 1 Mix FX 2 Mix

OLED Display

Able to access all parameters

Key Mode

Low High Last Low Retrigger High Retrigger Last Retrigger

Alternative Tuning

17 preset tunings

Trigger Input

Able to connect a general foot switch or input audio signals Able to set the operation from 4 types: Pedal Trigger Gate Trigger-Gate

MIDI

1 MIDI IN (5P DIN) 1 MIDI OUT/THRU (5P DIN)
