Tekniset tiedot

DMX Channels

8 or 14

DMX Connectors

3-pin XLR

Light Source

1 LED (white) 100 W, (27 A), 50,000 hours life expectancy

Strobe Rate

0 to 20 Hz

Illuminance

262,800 lux @ 2 m

Power Linking

5 units @ 120 V; 9 units @ 230 V

Input Voltage

100 to 240 VAC, 50/60 Hz (auto-ranging)

Power and Current

163 W, 1.5 A @ 120 V, 60 Hz 157 W, 0.8 A @ 230 V, 50 Hz

Weight

11.6 kg

Size

322 x 220 x 480 mm

Approvals

CE, MET

Beam Angle

3°

Optional Controllers

IRC - 6

Pan and Tilt

540°/270°

Pan and Tilt Ranges

180°, 360°, 540° pan/270°, 180°, 90° tilt

Colors

8 + white, split colors, continuous scroll at variable speeds

Gobos

5 + open, animation effect, continuous scroll at variable speeds

PWM Frequency

1.8 kHz [flicker free]
