Tekniset tiedot

DMX Channels

13 or 19

DMX Connectors

3-pin XLR

Light Source

(included): Osram Sirius HRI 140 W discharge lamp (6,000 hrs) (optional): Osram Sirius HRI 132 W discharge lamp (6,000 hrs)

Strobe Rate

0 to 20 Hz

Illuminance

(3° beam): 382,000 lux @ 5 m (7° spot): 104,700 lux @ 5 m (14° wash): 4,680 lux @ 5 m

Power Linking

3 units @ 120 V; 6 units @ 230 V

Input Voltage

100 to 240 VAC, 50/60 Hz (auto-ranging)

Power and Current

260 W, 2.5 A @ 120 V, 60 Hz 254 W, 1.3 A @ 230 V, 50 Hz

Gobo Size

(rotating): 13.7 mm outside, 11 mm image, 1 mm max thickness

Zoom Angle

(beam): 3° to 11° (spot): 7° to 21° (wash): 14° to 28°

Weight

15.2 kg

Size

322 x 220 x 513 mm

Approvals

CE, MET

Pan and Tilt

540°/270°

Pan and Tilt Ranges

180°, 360°, 540° pan/90°, 180°, 270° tilt

Colors

12 + white, split colors, continuous scroll at variable speeds

Gobos

wheel (1): 9 + open, rotating, indexing, interchangeable, slot-n-lock, continuous scroll at variable speeds wheel (2): 17 + open, aluminum, continuous scroll at variable speeds

Prism

(1): 8-facet round, bidirectional rotation at variable speeds, (2): 6-facet linear, bidirectional rotation at variable speeds
