Tekniset tiedot

DMX Channels

9 or 15

DMX Connectors

3-pin XLR

Light Source

1 LED (white) 150 W, (12.3 A), 50,000 hours life expectancy

Strobe Rate

0 to 20 Hz

Illuminance

(10°): 38,000 lux @ 2 m (23°): 19,850 lux @ 2 m

Power Linking

3 units @ 120 V; 5 units @ 230 V

Input Voltage

100 to 240 VAC, 50/60 Hz (auto-ranging)

Power and Current

277 W, 2.5 A @ 120 V, 60 Hz 268 W, 1.3 A @ 230 V, 50 Hz

Gobo Size

24 mm outside, 20 mm image, 1 mm max thickness

Zoom Angle

10° to 23°

Weight

12.4 kg

Size

220 x 322 x 466 mm

Approvals

CE, MET

Optional Controllers

IRC - 6

Pan and Tilt

540°/270°

Pan and Tilt Ranges

540°, 360°, 180° pan/270°, 180°, 90° tilt

Colors

7 + white, split colors, continuous scroll at variable speeds

Gobos

7 + open (6 aluminum + 1 glass), rotating, interchangeable, indexing, slot-n-lock, continuous scroll at variable speeds

PWM Frequency

1.8 kHz

Prism

(1): 6-facet round, bidirectional rotation at variable speeds,(2): 5-facet linear, bidirectional rotation at variable speeds
