Tekniset tiedot

DMX Channels

14, or 29

DMX Connectors

3-pin XLR

Light Source

12 LEDs (quad-color RGBW) 15 W (3.7 A), 50,000 hours life expectancy

Strobe Rate

0 to 20 Hz

Illuminance

(14°): 25,610 lux @ 2 m (58°): 1,960 lux @ 2 m

Power Linking

4 units @ 120 V; 8 units @ 230 V

Input Voltage

100 to 240 VAC, 50/60 Hz (auto-ranging)

Power and Current

219 W, 1.9 A @ 120 V, 60 Hz 207 W, 1 A @ 230 V, 50 Hz

Zoom Angle

14° to 58°

Weight

7.2 kg

Size

194 x 277 x 363 mm

Approvals

CE

Optional Controllers

IRC-6

Pan and Tilt

540°/270°

Pan and Tilt Ranges

540°, 360°, 180° pan/270°, 180°, 90° tilt

PWM Frequency

1,200 Hz
